Gasoline Powered 5RPM Cable Winch Puller

Name: Gasoline Powered 5RPM Cable Winch Puller
Brand: Donghuan
Price: 1 USD

Buy cheap Gasoline Powered 5RPM Cable Winch Puller product

Brand Name : Donghuan

Model Number : JJQ-30

Certification : ISO

Place of Origin : Ningbo,China

MOQ : Negotiation

Price : Negotiation

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 1000 sets per month

Delivery Time : 3-5 workdays

Packaging Details : Exported Plywood Case

Name : Cable Winch Puller

Feature : Fast Traction Speed

rotational Speed : 5 RPM

Traction Speed : 5 M/MIN

Tractive force : 3 T

Power : 4.04

Contact Now

Gasoline Powered Cable Winch Puller With Fast Traction Speed 5 M/MIN

Cable Winch Puller Features

1. High versatility

2. Compactstructure

3. Smallvolume, lightweight, convenience in using and transferring

4. Driving stably

5. Very light noise

6. With big drum rope capacity to make you a wide range of choice for the lifting height or pulling length.

7. Adjustable lifting or pulling speed for different usage environment.

Cable Winch Puller Specifications:

Item number	Model	Rotation	Gear	(T)	(M/MIN)	(KW)	(MM)	(KG)
		direction		Tractive	Traction	Power	Outline	Weight
				force	speed		size
9131	JJQ-30		SlowⅠ	3	5	4.04	900x400x430	94
			SlowⅠ	3	5
	6HP	corotation	SlowⅡ	2	7
			FastⅠ	0.9	16
	Gasoline		FastⅡ	0.6	24
			Slow		4
	engine		Slow		4
		reversal	Fast	No lifting	13
09131A	JJC-3		SlowⅠ	3	5	2.9	1000x450x500	115
		corotation
	5HP

			SlowⅡ	2	7
			FastⅠ	0.9	16
	Diesel		FastⅡ	0.6	24
			Slow		4
	engine	reversal	Fast	No lifting	13
9135	JJQ-5B		FastⅠ	0.9	24	6.6	1100x525x600	138

	9HP	corotation

			FastⅡ	1.5	13
			SlowⅠ	2.5	8
	Gasoline		SlowⅡ	5	4
			Slow		4
	engine	reversal	Fast	No lifting	18
09135A	JJC-5B		FastⅠ	0.9	24	5.7	1000x498x600	148
		corotation
	186F

			FastⅡ	1.5	13
			SlowⅠ	2.5	8
	Diesel		SlowⅡ	5	4
			Slow		4
	engine	reversal	Slow	No lifting	18

Configuration:

Uses:suitable for the construction of the tower line,traction line,tight line operation,laying cable.

Explain:

Power can be configured according to used requirements.

Cable Winch Puller Pictures

Gasoline Powered 5RPM Cable Winch Puller
